- 3pt linkage, centrally mounted
- Floating clevis hitch with Cat 2 pins (Cat 2/3 pins on the 3500 & 4000)
- Drive shaft with 1 3/8″ 6 spline yoke and fitted with friction plate clutch
- 140 hp, single speed gearbox
- Rotor speeds of: 348 rpm at 540 rpm PTO or 362 rpm at 1000 rpm PTO (Additional gears for other speeds available as an option)
- Front square tube 80mm x 80mm x 6mm (2500 & 3000) and 80mm x 120mm x 6mm (3500& 4000)
- Tapered Roller Bearings on all rotor output shafts
- Quick release tynes
- Rear PTO shaft for ancillary equipment
- Rear levelling bar with manual ‘screw’ type adjustment system
- Round tyne mounting flange (to which an optional stone protector can be fitted)
- Full CE safety guarding on all models
- Depth control via 8 Tube Cage Roller
- Side protection shields
